CKAD Preparation, Testing Kubernetes NetworkPolicy

Published on October 18, 2025 • By Hiro
CKAD Preparation, Testing Kubernetes NetworkPolicy

Introduction

This article is part of an ongoing series designed to help you prepare for the Certified Kubernetes Application Developer (CKAD) exam through small, focused labs.

In this post, we’ll cover the requirements within the “Services and Networking” domain:

Demonstrate basic understanding of NetworkPolicies

Here we’ll demonstrate how to restrict ingress traffic using a Kubernetes NetworkPolicy.

You can start from the beginning of the series here: CKAD Preparation — What is Kubernetes.

Prerequisites

⚠️ Important: Verify that your Kubernetes cluster is configured with a CNI plugin that implements NetworkPolicy. Without such support, any defined policies will be silently ignored. I ran some local tests with Kubernetes on Docker Desktop and with minikube, but neither supports them natively. In the end I opted for a temporary environment using one of the KillerCoda Kubernetes Playgrounds

Getting the Resources

All manifests and examples mentioned in this post are available in the following repository:

git clone https://github.com/SupaaHiro/schwifty-lab.git
cd schwifty-lab/blog-posts/20251018-ckad

Creating the Redis Pod

To understand how Network Policies work, we need to create a couple of pods. Here’s the first one:

apiVersion: v1
kind: Pod
metadata:
  name: redis
  labels:
    app: redis
spec:
  containers:
    - name: redis
      image: redis:alpine
      ports:
        - containerPort: 6379

This pod creates a redis instance listening on port 6379.

Apply the manifest:

k create -f manifests/01-redis.yaml

Verify the Pod reaches the Running state:

k get pod -o=wide -l=app=redis --watch

Creating the Service

To make Redis accessible to other Pods, create a ClusterIP Service.

apiVersion: v1
kind: Service
metadata:
  name: redis
  labels:
    app: redis
spec:
  type: ClusterIP
  selector:
    app: redis
  ports:
    - port: 6379
      targetPort: 6379

Apply the manifest:

k create -f manifests/02-redis-svc.yaml

Once applied, check that the endpoint is correctly populated with:

k get svc -l=app=redis -o=wide
k describe svc redis

Example output:

Name:                     redis
Namespace:                default
Labels:                   app=redis
Annotations:              <none>
Selector:                 app=redis
Type:                     ClusterIP
IP Family Policy:         SingleStack
IP Families:              IPv4
IP:                       10.105.198.164
IPs:                      10.105.198.164
Port:                     <unset>  6379/TCP
TargetPort:               6379/TCP
Endpoints:                10.1.0.174:6379
Session Affinity:         None
Internal Traffic Policy:  Cluster
Events:                   <none>

Connectivity test script

To verify connectivity to Redis we’ll use a simple Python script.

The script tries to connect to the Redis service and prints a success or error message, with a configurable timeout (default 10 seconds).

import os
import redis

host = os.getenv("REDIS_HOST", "redis")
port = int(os.getenv("REDIS_PORT", "6379"))
timeout = int(os.getenv("REDIS_TIMEOUT", "10"))

try:
    client = redis.Redis(
        host=host,
        port=port,
        socket_connect_timeout=timeout,
        socket_timeout=timeout
    )
    client.ping()
    print(f"✅ Connected to Redis at {host}:{port} (timeout={timeout}s)")
except Exception as e:
    print(f"❌ Failed to connect to Redis: {e}")

To avoid creating a dedicated Docker image, we will mount the script as a volume via a ConfigMap:

k create cm test-redis-ping --from-file=test-redis-ping.py=./src/test-redis-ping.py

Creating the Client Pod

Define a Pod called redis-client, based on python:3.12-alpine. The container will install the redis library on the fly and then run the script mounted from the ConfigMap.

apiVersion: v1
kind: Pod
metadata:
  name: redis-client
  labels:
    app: redis-client
spec:
  containers:
    - name: python-tester
      image: python:3.12-alpine
      command:
      - sh
      - -c
      - >
        pip install --upgrade pip --root-user-action ignore > /dev/null &&
        pip install redis --root-user-action ignore > /dev/null &&
        python /scripts/test-redis-ping.py
      env:
        - name: REDIS_HOST
          value: "redis"
        - name: REDIS_PORT
          value: "6379"
      volumeMounts:
        - name: script-volume
          mountPath: /scripts
  volumes:
    - name: script-volume
      configMap:
        name: test-redis-ping
  restartPolicy: Never

Apply the manifest:

k create -f manifests/03-redis-client.yaml

Wait for the Pod to be Running and check the logs:

k get pod -o=wide -l=app=redis-client --watch
k logs redis-client

If everything works, we should see:

✅ Connected to Redis at redis:6379

Defining the NetworkPolicy

Create two NetworkPolicy resources:

  • default-deny-ingress — blocks all incoming traffic by default.
  • redis-access — allows access to the Redis Pod only from Pods that have the label access: redis.
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: default-deny-ingress
spec:
  podSelector: {}
  policyTypes:
    - Ingress
  ingress: []
---
apiVersion: networking.k8s.io/v1
kind: NetworkPolicy
metadata:
  name: redis-access
spec:
  podSelector:
    matchLabels:
      app: redis
  policyTypes:
    - Ingress
  ingress:
    - from:
        - podSelector:
            matchLabels:
              access: redis
      ports:
        - protocol: TCP
          port: 6379

Apply the manifest:

k create -f manifests/04-netpol.yaml

After applying, the redis-access policy will act like a “fence” around Pods with label app=redis, allowing connections only from Pods labeled with access=redis.

Testing the blocked connection

Currently the redis-client Pod does not have the label access: redis, so the connection should fail.

Remove and recreate the Pod, then check the logs:

k replace -f manifests/03-redis-client.yaml --force
k logs redis-client

The expected result is a timeout error:

❌ Failed to connect to Redis: Timeout connecting to server

Note: the error may take a few seconds to appear in the logs.

Enable access via label

Add the missing label “access: redis” to the redis-client Pod manifest and recreate it:

yq e '.metadata.labels.access = "redis"' -i manifests/03-redis-client.yaml
k replace -f manifests/03-redis-client.yaml --force

After the deploy, the connection should work again:

✅ Connected to Redis at redis:6379

🏁 Wrapping Up: What We’ve Covered

In this article we reviewed a practical workflow to test Kubernetes Ingress NetworkPolicy using a Redis server and a client Pod. Key takeaways:

  • Ensure your cluster uses a CNI that implements NetworkPolicy; without CNI support, NetworkPolicy objects are ignored.
  • Use a “default-deny” Ingress policy to block all incoming traffic by default, then add explicit allow rules to scope access (for example, by pod labels).
  • NetworkPolicies are applied to Pods (via podSelector) — label your Pods intentionally to control access and to make policies predictable.
  • Test connectivity with a lightweight client Pod and a configurable script (mounted via ConfigMap); check Pod logs for connection timeouts or success messages to validate policy effects.

Final cleanup

When you’re done with the experiments, remove all created resources (Pods, Service and NetworkPolicy) to clean up the environment:

k delete svc redis
k delete netpol default-deny-ingress redis-access
k delete po redis redis-client
