CKAD Preparation — Utilize Persistent and Ephemeral Volumes

Published on October 23, 2025 • By Hiro
CKAD Preparation — Utilize Persistent and Ephemeral Volumes

Introduction

This article is part of an ongoing series designed to help you prepare for the Certified Kubernetes Application Developer (CKAD) exam through small, focused labs.

In this post, we’ll cover the requirements within the “Application Design and Build” domain:

Utilize persistent and ephemeral volumes

Here we’ll cover how to utilize persistent and ephemeral volumes — a fundamental CKAD topic for managing stateful workloads and inter-container data sharing.

You can start from the beginning of the series here: CKAD Preparation — What is Kubernetes.

Prerequisites

A running Kubernetes cluster (like, Minikube, Docker Desktop, or use one of the KillerCoda Kubernetes Playgrounds) and basic familiarity with Pods and YAML manifests.

Getting the Resources

Clone the lab repository and navigate to this article’s folder:

git clone https://github.com/SupaaHiro/schwifty-lab.git
cd schwifty-lab/blog-posts/20251023-ckad

Understanding Volumes in Kubernetes

Containers are ephemeral by design: once restarted or rescheduled, their filesystem state is lost. We can overcome this limitation in Kubernetes by using volumes — directories that provide persistent storage accessible to containers within a Pod.

There are two main volume types to know for the CKAD exam:

  • Ephemeral volumes — created and destroyed with the Pod. Examples: emptyDir, configMap, secret, downwardAPI, and ephemeral.
  • Persistent volumes — survive Pod restarts, backed by cluster-level resources such as PersistentVolume (PV) and PersistentVolumeClaim (PVC).

Note: Downward API volumes expose Pod metadata and resource information (such as labels or CPU limits) to containers as files. We’ll explore this in a dedicated article.

Ephemeral Volumes (emptyDir)

An emptyDir volume is created when a Pod is scheduled on a node and deleted when the Pod is removed. It’s ideal for temporary data, caching, or communication between containers.

Persistent Volumes (PVC)

Persistent volumes are used when data must outlive a Pod’s lifecycle — for example, application databases or user-generated content. A Pod mounts a PersistentVolumeClaim (PVC), which is a request for storage resources in the cluster. The PVC then binds to a PersistentVolume (PV) provisioned by the cluster or dynamically by a storage class.

Hands-On Challenge

In this exercise you’ll create:

  • A Pod with ephemeral storage shared between two containers.
  • A Deployment using a PersistentVolumeClaim for long-lived storage.

🧩 Step 1 — Ephemeral Volume with emptyDir

Create a Pod with:

  • A busybox writer container that writes a timestamp every 3 seconds to a shared file.
  • A busybox reader container that continuously prints that same file.
apiVersion: v1
kind: Pod
metadata:
  name: ephemeral-volume-demo
spec:
  containers:
  - name: writer
    image: busybox:1.37
    command: ["/bin/sh", "-c", "while true; do date >> /data/time.log; sleep 3; done"]
    volumeMounts:
    - name: shared-data
      mountPath: /data
  - name: reader
    image: busybox:1.37
    command: ["/bin/sh", "-c", "tail -f /data/time.log"]
    volumeMounts:
    - name: shared-data
      mountPath: /data
  volumes:
  - name: shared-data
    emptyDir: {}
  restartPolicy: Always

Save it as manifests/01-ephemeral-pod.yaml and apply:

k apply -f manifests/01-ephemeral-pod.yaml
k get pod ephemeral-volume-demo --watch

Once running, check logs from the reader container:

k logs -f ephemeral-volume-demo -c reader

You should see timestamps being continuously appended — proof that both containers share the same emptyDir.

💾 Step 2 — Persistent Volume Claim (PVC)

Now let’s create a PersistentVolumeClaim and mount it into a Deployment.

First, create a PVC manifest (manifests/02-pvc.yaml):

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: demo-pvc
spec:
  accessModes:
  - ReadWriteOnce
  resources:
    requests:
      storage: 100Mi

Apply it:

k apply -f manifests/02-pvc.yaml
k get pvc demo-pvc

Then create a Deployment that mounts this PVC into an Nginx container.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: nginx-pvc
spec:
  replicas: 1
  selector:
    matchLabels:
      app: nginx-pvc
  template:
    metadata:
      labels:
        app: nginx-pvc
    spec:
      containers:
      - name: nginx
        image: nginx:1.27
        volumeMounts:
        - name: persistent-storage
          mountPath: /usr/share/nginx/html
      volumes:
      - name: persistent-storage
        persistentVolumeClaim:
          claimName: demo-pvc

Apply it:

k apply -f manifests/03-nginx-pvc.yaml

Create a test file inside the Pod and verify persistence:

k exec -it deploy/nginx-pvc -- /bin/sh
echo "Hello from PVC" > /usr/share/nginx/html/index.html
exit

Now delete the Pod and let the Deployment recreate it:

k delete pod -l app=nginx-pvc
k exec -it deploy/nginx-pvc -- cat /usr/share/nginx/html/index.html

✅ You’ll see the same “Hello from PVC” content — confirming that the data persisted even after Pod recreation.

Wrapping Up: What We’ve Covered

In this exercise, we practiced how to use both ephemeral and persistent storage in Kubernetes. We built:

  • A multi-container Pod that shared temporary data using an emptyDir volume.
  • A Deployment using a PersistentVolumeClaim to retain data across Pod restarts.

Understanding when to use ephemeral vs persistent volumes is essential for designing robust, CKAD-ready applications. Ephemeral volumes are perfect for transient data (logs, caches, scratch space), while persistent volumes ensure state durability across restarts and rescheduling events.

📝 In later modules, we’ll explore StatefulSets and dynamic provisioning for stateful workloads like databases.

Final cleanup

When done, remove all resources:

k delete -f manifests/
