Introduction
This article is part of an ongoing series designed to help you prepare for the Certified Kubernetes Application Developer (CKAD) exam through small, focused labs.
In this post, we’ll cover the requirements within the “Application Deployment” domain:
Implement Blue/Green and Canary deployments using Kubernetes primitives
Here we’ll cover how to implement Blue/Green and Canary deployments — a fundamental CKAD topic for managing application rollout strategies and minimizing downtime.
You can start from the beginning of the series here: CKAD Preparation — What is Kubernetes.
Prerequisites
A running Kubernetes cluster (like, Minikube, Docker Desktop, or use one of the KillerCoda Kubernetes Playgrounds) and basic familiarity with Pods and YAML manifests.
Getting the Resources
Clone the lab repository and navigate to this article’s folder:
git clone https://github.com/SupaaHiro/schwifty-lab.git
cd schwifty-lab/blog-posts/20251121-ckad
Understanding Deployment Strategies in Kubernetes
Modern application delivery often requires updating workloads with zero downtime. Kubernetes provides native primitives — Deployments, Services, labels, and rolling updates — that make it possible to implement common release strategies without relying on external tools.
In this exercise, we focus on two CKAD-relevant patterns:
- Blue/Green deployments — keep two versions running side by side and switch traffic by updating labels and selectors.
- Canary deployments — send a small portion of traffic to the new version for validation before rolling it out fully.
Both examples rely only on Kubernetes-native mechanisms.
Hands-On Challenge: Blue/Green Deployment
A Blue/Green deployment uses two identical environments: one running the current version (Blue) and the other running the new version (Green).
We’ll run two Deployments:
- blue-app — version 1
- green-app — version 2
Traffic will be routed through a Service that selects which version to expose.
Before starting, create a ConfigMap containing two simple HTML files representing each version’s “color.”
apiVersion: v1
kind: ConfigMap
metadata:
name: web-assets
data:
blue.html: |
<html>
<body>
<div>Hello, it's BLUE !</div>
</body>
</html>
green.html: |
<html>
<body>
<div>Hello, it's GREEN !</div>
</body>
</html>
Apply it:
k apply -f manifests/00-web-assets.yaml
Alternatively, you can create it directly from files. During the exam, you might prefer this method to save time.
k create configmap web-assets --from-file=assets/blue.html --from-file=assets/green.html
Now we can create the Blue deployment manifest:
apiVersion: apps/v1
kind: Deployment
metadata:
name: blue-app
spec:
replicas: 1
selector:
matchLabels:
app: demo
version: blue
template:
metadata:
labels:
app: demo
version: blue
spec:
volumes:
- name: web-assets
configMap:
name: web-assets
items:
- key: blue.html
path: index.html
containers:
- name: app
image: nginx:1.29.3-perl
env:
- name: COLOR
value: "blue"
volumeMounts:
- name: web-assets
mountPath: "/usr/share/nginx/html"
readOnly: true
Apply it:
k apply -f manifests/01-blue.yaml
Next, create the Green deployment:
apiVersion: apps/v1
kind: Deployment
metadata:
name: green-app
spec:
replicas: 1
selector:
matchLabels:
app: demo
version: green
template:
metadata:
labels:
app: demo
version: green
spec:
volumes:
- name: web-assets
configMap:
name: web-assets
items:
- key: green.html
path: index.html
containers:
- name: app
image: nginx:1.29.3-perl
env:
- name: COLOR
value: "green"
volumeMounts:
- name: web-assets
mountPath: "/usr/share/nginx/html"
readOnly: true
Apply it:
k apply -f manifests/02-green.yaml
Confirm both versions are running:
k get pods -l app=demo
We should get two pods running, one for each version.
NAME READY STATUS RESTARTS AGE
blue-app-674544c6cf-vfnc9 1/1 Running 0 8m17s
green-app-76897ccfb6-n29b4 1/1 Running 0 7m50s
Create a Service that initially routes traffic to the blue version:
apiVersion: v1
kind: Service
metadata:
name: demo-svc
spec:
selector:
app: demo
version: blue
ports:
- port: 80
targetPort: 80
Apply it:
k apply -f manifests/03-service.yaml
Let’s check that the traffic goes to the blue deployment:
k run -it --rm --image=curlimages/curl --restart=Never -- curl demo-svc
By patching the Service selector, we can switch traffic to the green deployment:
k patch svc demo-svc -p '{"spec":{"selector":{"app":"demo","version":"green"}}}'
If we run the curl command again we should now hit the green version:
k run -it --rm --image=curlimages/curl --restart=Never -- curl demo-svc
Hands-On Challenge: Canary Deployment
A canary deployment gradually introduces a new version to a subset of users before rolling it out completely. Kubernetes Services do not natively support traffic weighting, but we can simulate it by adjusting replica counts.
We’ll create two Deployments:
- stable-app — the stable version
- canary-app — the new version with fewer replicas
Both will be selected by the same Service, allowing traffic distribution to follow replica proportions.
This is the manifest for the stable version:
apiVersion: apps/v1
kind: Deployment
metadata:
name: stable-app
spec:
replicas: 4
selector:
matchLabels:
app: canary-demo
template:
metadata:
labels:
app: canary-demo
version: stable
spec:
containers:
- name: app
image: nginx:1.29.3-perl
Apply it:
k apply -f manifests/04-stable.yaml
This is the manifest for the canary version:
apiVersion: apps/v1
kind: Deployment
metadata:
name: canary-app
spec:
replicas: 1
selector:
matchLabels:
app: canary-demo
version: canary
template:
metadata:
labels:
app: canary-demo
version: canary
spec:
containers:
- name: app
image: nginx:1.29.3-perl
env:
- name: CANARY
value: "true"
Apply it:
k apply -f manifests/05-canary.yaml
Create a Service that selects both deployments:
apiVersion: v1
kind: Service
metadata:
name: canary-svc
spec:
selector:
app: canary-demo
ports:
- port: 80
targetPort: 80
Apply it:
k apply -f manifests/06-service.yaml
Now, let’s test traffic distribution:
for i in {1..20}; do
k run -it --rm --image=curlimages/curl --restart=Never curl canary-svc
done
We do expect to see:
- Most responses hit stable-app (4 replicas).
- Some responses hit canary-app (1 replica).
This simulates a real canary rollout: the new version receives a small amount of traffic for validation.
If everything looks good with the canary, we can promote it by scaling up the canary and scaling down the stable:
k scale deploy/stable-app --replicas=0
You’ve completed a manual canary promotion using Kubernetes-native mechanisms only.
Wrapping Up: What We’ve Covered
In this exercise, we practiced how to implement Blue/Green and Canary deployments using only Kubernetes-native constructs.
Here’s a quick recap:
- Blue/Green deployment implemented through label switching and Service routing.
- Canary rollout simulated by distributing traffic based on replica counts.
While these approaches are valid for CKAD and effective for controlled scenarios, Kubernetes provides only basic primitives for rollout strategies. Traffic routing is binary — a Pod either matches a selector or it doesn’t — and there’s no native support for precise percentage-based routing, custom metrics, or automated progressive analysis.
In production environments, these limitations are commonly addressed through:
- Advanced CNIs, which offer more granular traffic control.
- Service mesh layers such as Istio, which enable weighted routing, automated rollback, request-level policies, and shadow deployments.
📝 In later modules, we’ll explore these components and see how they unlock more advanced deployment patterns beyond what Kubernetes provides natively.
Final cleanup
When you’re done, remove all resources:
k delete -f manifests/
