CKA Preparation — Resource Allocation Based on Node Availability

Published on December 29, 2025 • By Hiro
CKA Preparation — Resource Allocation Based on Node Availability

Introduction

It’s been more than a month since I published an article on the blog! Mainly due to work deadlines, but also because I was preparing to renew my CKA certification.

In this article, I would like to share with you an exercise that I came across during my exam preparation, concerning resource allocation based on node availability. This is an exercise that seems easy at first glance, but it hides some traps along the way.

This article is not part of the CKAD series: If you want to start preparing for the CKAD certification, you can begin here: CKAD Preparation — What is Kubernetes.

Prerequisites

A running Kubernetes cluster (like, Minikube, Docker Desktop, or use one of the KillerCoda Kubernetes Playgrounds) and basic familiarity with Pods and YAML manifests.

Optionally, a metrics server (for example metrics-server) can be installed in the cluster to monitor resource usage. You can install it by running the following command:

k apply -f https://github.com/kubernetes-sigs/metrics-server/releases/latest/download/components.yaml

In case of TLS issues, modify the metrics-server deployment to add the --kubelet-insecure-tls argument to the container.

k -n kube-system edit deployment metrics-server
# In spec.template.spec.containers[].args add:
# - --kubelet-insecure-tls

Getting the Resources

Clone the CKA-PREP-2025-v2 repository and start the exercise like this:

git clone https://github.com/SupaaHiro/CKA-PREP-2025-v2
cd CKA-PREP-2025-v2
bash ./scripts/run-question.sh 'Question-4 Resource-Allocation'

Note: This repo is a fork of the vj2201/CKA-PREP-2025-v2 repository with some minor modifications, mainly to keep notes for myself and do experiments.

Practical Exercise: Resource Allocation Based on Node Availability

After launching the exercise, you should see a prompt similar to this:

==> Running lab setup for Question-4 Resource-Allocation
deployment.apps/wordpress created

==> Question
# Question
# You are managing a WordPress application running in a Kubernetes cluster
# Your task is to adjust the Pod resource requests and limits to ensure stable operation

# Tasks
# 1. Scale down the wordpress deployment to 0 replicas
# 2. Edit the deployment and divide the node resource evenly across all 3 pods
# 3. Assign fair and equal CPU and memory to each Pod
# 4. Add sufficient overhead to avoid node instability
# Ensure both the init containers and the main containers use exactly the same resource requests and limits
# After making the changes scale the deployment back to 3 replicas

#Video link - https://youtu.be/ZqGDdETii8c

Hints: see Question-4 Resource-Allocation/SolutionNotes.bash

The first thing we’re asked to do is scale the wordpress deployment down to 0 replicas. Let’s do this:

k scale deploy wordpress --replicas 0

Before we can resize the deployment, we need to calculate how many resources we can assign to each Pod. To do this, let’s check how many resources are available on the node:

k describe node node01 | grep "Allocatable:" -A5

We should see something similar to this:

Allocatable:
  cpu:                1
  memory:             1846540Ki
  pods:               110

For simplicity, let’s assume that our cluster has a single worker node available, in this case with 1 CPU and approximately 1.8 GiB of allocatable memory.

These values already take into account the resources used by the system and by kubelet. However, from these values we need to subtract the resources already in use by existing Pods.

k describe node node01 | grep "Allocated resources:" -A5

We should see something similar to this:

Allocated resources:
  (Total limits may be over 100 percent, i.e., overcommitted.)
  Resource           Requests     Limits
  --------           --------     ------
  cpu                225m (22%)   0 (0%)
  memory             300Mi (16%)  340Mi (18%)

Now we need to do some calculations. We can use up to 1 CPU - 225m = 775m CPU and 1.8 GiB - 300 MiB = approximately 1.5 GiB of memory for our Pods.

We have 3 replicas, so let’s divide these resources by 3:

  • CPU per Pod: 775m / 3 ≈ 258m
  • Memory per Pod: 1.5 GiB / 3 = 512 Mi

To perform the calculations from the terminal, we can use bc like this:

1000 * (1 - 0.225) / 3 -> 258
1846540/1024 *  (1 - 0.16) / 3 -> 504

Note: To exit bc, type quit.

So, the maximum limits we can assign to each Pod are:

  • CPU per Pod: 258m
  • Memory per Pod: 504 Mi

Let’s round down the limit values:

  • CPU Limit per Pod: 250m
  • Memory Limit per Pod: 500 Mi

Now that we know the limits, we need to leave some margin to avoid node instability. Let’s assign 95% of the limits as requests:

  • CPU Request per Pod: 237m (95% of the limit)
  • Memory Request per Pod: 475 Mi (95% of the limit)

Now we can modify the wordpress deployment to set the resource requests and limits for the main containers and the init containers. Let’s open the deployment manifest:

k edit deploy wordpress

Let’s add the following resources sections under the main containers and the init containers:

    spec:
      containers:
      - image: wordpress:6.2-apache
        name: wordpress
        resources:          # edit this section
          limits:
            cpu: 250m
            memory: 500Mi
          requests:
            cpu: 237m
            memory: 475Mi

Similarly, let’s assign the same resources to the init containers as well.

After saving the changes, let’s scale the wordpress deployment back to 3 replicas:

k scale deploy wordpress --replicas 3

After a while, the pods should be running.

Let’s verify the status of the Pods:

k get pods -l app=wordpress

We should see something similar to this:

NAME                         READY   STATUS    RESTARTS   AGE
wordpress-5d7f9c6b7b-abcde   1/1     Running   0          30s
wordpress-5d7f9c6b7b-fghij   1/1     Running   0          30s
wordpress-5d7f9c6b7b-klmno   1/1     Running   0          30s

Let’s double-check the allocated resources on the node to make sure everything is correct:

k describe node node01 | grep "Allocated resources:" -A5

We should see something similar to this:

Allocated resources:
  (Total limits may be over 100 percent, i.e., overcommitted.)
  Resource           Requests      Limits
  --------           --------      ------
  cpu                936m (93%)    750m (75%)
  memory             1725Mi (95%)  1840Mi (102%)

Perhaps we’re slightly overcommitted with the memory limit, but that’s okay—the important thing is that the requests are within the node’s limits.

There we go! We’ve completed the resource allocation exercise based on node availability.

Wrapping Up: What We’ve Covered

In this article, we’ve seen how to calculate and allocate resources to Pods in a Kubernetes cluster based on node availability. We’ve learned to:

  • Verify the allocatable and already allocated resources on the node.
  • Calculate the available resources for the Pods.
  • Modify a deployment to set resource requests and limits.

I hope this article has been helpful in your preparation for the CKA certification. Good luck with your studies, and see you next time!
