CKAD Preparation — Use the Helm package manager to deploy existing packages

Published on January 02, 2026 • By Hiro
CKAD Preparation — Use the Helm package manager to deploy existing packages

Introduction

This article is part of an ongoing series designed to help you prepare for the Certified Kubernetes Application Developer (CKAD) exam through small, focused labs.

In this article, we’ll cover the requirements within the “Application Deployment” domain:

Use the Helm package manager to deploy existing packages

We’ll explore what Helm is, how to install it, and how to use it to deploy applications in a Kubernetes cluster.

You can start from the beginning of the series here: CKAD Preparation — What is Kubernetes.

Prerequisites

A running Kubernetes cluster (like, Minikube, Docker Desktop, or use one of the KillerCoda Kubernetes Playgrounds) and basic familiarity with Pods and YAML manifests.

Getting the Resources

Clone the lab repository and navigate to this article’s folder:

git clone https://github.com/SupaaHiro/schwifty-lab.git
cd schwifty-lab/blog-posts/20260102-ckad

Hands-on Exercise: Let’s Use Helm to Deploy an Application

Before we dive into this hands-on exercise, it’s important to understand what Helm is and why it’s useful. In essence, Helm does for Kubernetes what apt, yum, or Homebrew do for operating systems: it simplifies the installation, upgrading, and management of complex applications.

When we deploy an application on Kubernetes, we often need to create and manage many different resources (Pods, Services, ConfigMaps, Secrets, etc.). Kubernetes knows how to handle these resources, but it doesn’t have visibility into how they work together to form a complete application. This is where Helm comes in. Helm uses “charts,” which are pre-configured packages of Kubernetes resources. These charts can be easily installed, upgraded, or removed with simple Helm commands, significantly simplifying application management on Kubernetes.

There are several public Helm chart repositories, such as Artifact Hub, which hosts thousands of charts for various applications.

Let’s start by installing Helm, following the official instructions in the official documentation.

On a Debian/Ubuntu-based system, you can install Helm with the following commands:

$ curl -fsSL -o get_helm.sh https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-4
$ chmod 700 get_helm.sh
$ ./get_helm.sh

Verify that Helm was installed correctly by checking the version:

helm version

You should see output similar to this:

version.BuildInfo{Version:"v4.0.4", GitCommit:"8650e1dad9e6ae38b41f60b712af9218a0d8cc11", GitTreeState:"clean", GoVersion:"go1.25.5", KubeClientVersion:"v1.34"}

To understand how Helm works, we’ll create a simple Helm chart to deploy a small Nginx-based web application. A quick way to create a sample chart is to use the helm create command, which generates a basic directory structure for a Helm chart.

helm create my-nginx-app

This command should create a directory called my-nginx-app with the following structure:

my-nginx-app/
  Chart.yaml
  values.yaml
  templates/
    deployment.yaml
    service.yaml
    _helpers.tpl
    .. other files ..

Since the generated example might be more complex than necessary for this exercise, let’s simplify the chart by removing unnecessary files and modifying the manifests to fit our simple Nginx application.

You can directly use the example in the charts/my-nginx-app folder as a reference for the modified files, or follow the instructions below to make the necessary changes.

If you’ve chosen to modify the files manually, proceed as follows:

  • Remove all files in the templates/ directory, keeping only deployment.yaml, service.yaml, _helpers.tpl, and NOTES.txt.

  • Replace the content of templates/deployment.yaml with the following:

apiVersion: apps/v1
kind: Deployment
metadata:
  name: { { include "my-nginx-app.fullname" . } }
spec:
  replicas: { { .Values.replicaCount } }
  selector:
    matchLabels:
      app: { { include "my-nginx-app.name" . } }
  template:
    metadata:
      labels:
        app: { { include "my-nginx-app.name" . } }
    spec:
      containers:
        - name: nginx
          image: ":"
          imagePullPolicy: { { .Values.image.pullPolicy } }
          ports:
            - containerPort: 80
          resources:
            limits:
              memory: 256Mi
              cpu: 200m
            requests:
              memory: 64Mi
              cpu: 50m

Note: The files in the templates/ folder are not just static YAML manifests. Helm uses Go Templating, a templating system that allows you to insert dynamic expressions within the YAML files.

  • Replace the content of templates/service.yaml with the following:
apiVersion: v1
kind: Service
metadata:
  name: { { include "my-nginx-app.fullname" . } }
spec:
  type: ClusterIP
  selector:
    app: { { include "my-nginx-app.name" . } }
  ports:
    - port: 80
      targetPort: 80
  • Replace the content of NOTES.txt with the following:
Nginx has been successfully installed 🎉

Release:
Namespace:

Replica Count:
Image: :

To check the status of the pods:
  kubectl get pods -l app= -n

To view the logs of the first pod:
  kubectl logs -l app= -n  --tail=100

To remove the release:
  helm uninstall  -n

------------------------------------------------------------
Accessing nginx

If you are running inside the cluster:
  curl http://..svc.cluster.local

If the Service type is ClusterIP (default), you can use port-forward:
  kubectl port-forward svc/ -n  8080:80
  curl http://localhost:8080

If the Service type is NodePort:
  kubectl get svc  -n
  # Then access using:
  http://<NodeIP>:<NodePort>

If the Service is exposed via Ingress:
  kubectl get ingress -n
  # Then access using the configured host name.
  • Finally, replace the content of values.yaml with the following:
replicaCount: 1

image:
  repository: nginx
  tag: "1.27"
  pullPolicy: IfNotPresent

Let’s finish by running a check to verify everything is in order:

helm lint my-nginx-app

You should see a message indicating that the chart is valid:

==> Linting my-nginx-app
[INFO] Chart.yaml: icon is recommended

1 chart(s) linted, 0 chart(s) failed

For third-party charts, it can be useful to examine the default configuration values and chart documentation before proceeding with installation.

You can do this using the helm show values, helm show readme, and helm show crds commands:

helm show values my-nginx-app
helm show readme my-nginx-app
helm show crds my-nginx-app

Obviously, our chart is very simple and doesn’t include CRDs, but in real-world scenarios these commands are very useful for understanding how to properly configure a chart before installation.

Before installing the chart, we can also generate the Kubernetes manifests that Helm will create for us using the helm template command. This allows us to see exactly which resources will be created in the cluster:

helm template my-nginx-app > ../manifests/nginx-manifests.yaml

If you want to modify any parameters, you can do so directly in the values.yaml file or pass custom values via the command line using the --set option.

helm template my-nginx-app --set replicaCount=2 > ../manifests/nginx-manifests.yaml

Now we’re ready to install our Helm chart in the Kubernetes cluster. Let’s use the helm install command to deploy the application:

helm install my-nginx-release my-nginx-app -n nginx --create-namespace

The above command will install the my-nginx-app chart with the release name my-nginx-release in the nginx namespace, creating the namespace if it doesn’t already exist.

You can verify that the deployment and service were created successfully with the following command:

k get deploy,svc,po -n nginx

With the helm list or helm ls command, you can see all Helm releases installed in the cluster:

helm list -n nginx

With the helm status command, you can get detailed information about the release status:

helm status my-nginx-release -n nginx

The helm upgrade command allows you to update an existing release with new configurations or chart versions. For example, to upgrade the Nginx container image to version 1.29:

helm upgrade my-nginx-release my-nginx-app --set image.tag="1.29" -n nginx

Helm maintains a version history for each release:

helm history my-nginx-release -n nginx

Here’s an example output:

REVISION        UPDATED                         STATUS          CHART                   APP VERSION     DESCRIPTION
1               Tue Dec 30 18:32:22 2025        superseded      my-nginx-app-0.1.0      1.16.0          Install complete
2               Tue Dec 30 18:36:43 2025        deployed        my-nginx-app-0.1.0      1.16.0          Upgrade complete

This history is stored in secrets managed by Helm within the namespace where the release was installed:

k get secrets -n nginx

The helm rollback command allows you to revert to a previous version of the release if something goes wrong during an upgrade. For example, to roll back to revision 1:

helm rollback my-nginx-release 1 -n nginx

Keep in mind that the rollback itself generates a new release, so the history will show all versions, including rollbacks:

REVISION        UPDATED                         STATUS          CHART                   APP VERSION     DESCRIPTION
1               Tue Dec 30 18:32:22 2025        superseded      my-nginx-app-0.1.0      1.16.0          Install complete
2               Tue Dec 30 18:36:43 2025        superseded      my-nginx-app-0.1.0      1.16.0          Upgrade complete
3               Tue Dec 30 18:41:15 2025        deployed        my-nginx-app-0.1.0      1.16.0          Rollback to 1

Finally, when you no longer need the application, you can remove it with the helm uninstall command:

helm uninstall my-nginx-release -n nginx

To complete our overview of Helm, let’s see how to add an external Helm chart repository. For example, we can search for a WordPress application on Artifact Hub and add the official repository from Bitnami, which hosts a chart for WordPress.

helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo update

Now we can search for the WordPress chart in the Bitnami repository:

helm search repo bitnami/wordpress --versions

The --versions option shows all available versions of the chart.

We can install WordPress using the Bitnami chart with the following command:

helm install my-wordpress bitnami/wordpress -n wordpress --create-namespace --version 28.0.4 --set wordpressUsername=admin,wordpressPassword=pass123

With this command, Helm will download the WordPress chart from the Bitnami repository and install it in the wordpress namespace, creating the namespace if it doesn’t already exist. We’ve also specified some custom configurations, such as the WordPress username and password.

If we want to upgrade the WordPress version in the future, we can use the helm upgrade command:

helm upgrade my-wordpress bitnami/wordpress -n wordpress --version 28.1.0

If we look at the release history for WordPress, we’ll see the different versions that have been installed:

helm history my-wordpress -n wordpress

Here’s an example output:

REVISION        UPDATED                         STATUS          CHART                   APP VERSION     DESCRIPTION
1               Wed Dec 31 09:56:53 2025        superseded      wordpress-28.0.4        6.9.0           Install complete
2               Wed Dec 31 09:59:28 2025        deployed        wordpress-28.1.0        6.9.0           Upgrade complete

Recap: What We’ve Covered

In this exercise, we explored Helm, the Kubernetes package manager, and how it can significantly simplify application management.

We learned how to:

  • Install Helm on our system following the official documentation.
  • Create a basic Helm chart using the helm create command.
  • Customize Kubernetes templates within a chart to fit our needs.
  • Validate a chart with helm lint to ensure it’s properly configured.
  • View configuration values, documentation, and CRDs of a chart with helm show commands.
  • Generate Kubernetes manifests without installing them using helm template.
  • Install a chart in the cluster with helm install and verify its status.
  • Manage releases with helm list, helm upgrade, helm rollback, and helm history.
  • Completely remove an application with helm uninstall.
  • Add external chart repositories and install applications from them.

Helm is a fundamental tool in the Kubernetes ecosystem and represents an essential skill for the CKAD exam. The ability to use existing Helm charts, understand them, and customize them will allow you to deploy complex applications quickly and efficiently, while maintaining reproducibility and manageability over time.

In daily practice, Helm will save you valuable time and reduce configuration errors, allowing you to focus on the most important aspects of your application development.

Final Cleanup

To wrap up, let’s remove the namespaces created for this exercise:

k delete ns nginx
